TR04-20-XX-04(DALI) 20W LED Track Light

TR04-20-XX-04(DALI) 20W LED Track Light



♦ Controlled by in-track DALI-2 DT6 driver.
♦ Thoughtful friction on the track arm, get rid of loose track arm experience.
♦ Variety of less-glare optic options.
♦ 5-year guarantee.

info@nm-led.com

Tel: +86 75527615054

Whatsapp: 8675527615054

TR04-20-XX-04(DALI) 20W LED Track Light
TR04-20-XX-04(DALI) 20W LED Track Light
TR04-20-XX-04(DALI) 20W LED Track Light
TR04-20-XX-04(DALI) Data Sheet.pdf
description1
Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Product Description
Technical Data
Input Voltage/Hz AC200-240V   50/60Hz
Output Voltage/Current DC35V/470mA
Power 20W | 21W (HEP DALI)
21W | 22W(TRIDONIC DALI)
Rated Input Current 0.1A(HEP DALI) | 0.105A(TRIDONIC DALI)
THD <13%
PF value >0.9(HEP DALI) | >0.95(TRIDONIC DALI)
Ingress Protection IP20
Operating Temperature -10-40℃
Dimmability HEP (with NFC) DALI
TRIDONIC DALI



LED and Optical Data
LED Brand  Bridgelux COB LED
CRI  >80(HEP 20W), >90(HEP 21W)
>80(TRIDONIC 20W), >90(TRIDONIC 21W)
SDCM <6
Beam Angle 15°/25°/38°/60°
Colour temperature 2700K/3000K/4000K
System luminous efficacy up to 93lm/W



Packaging
Box Dimensions L296×W198×H68mm
Box Net Weight 0.428kg
Box Gross Weight 0.546kg
Carton Dimensions L610×W310×H292mm/12PCS
Carton Net Weight 5.136kg
Carton Gross Weight 6.552kg

Technical Data Download

TR04-20-XX-04(DALI) Technical Data
