♦ Controlled by in-track DALI-2 DT6 driver.
♦ Thoughtful friction on the track arm, get rid of loose track arm experience.
♦ Variety of less-glare optic options.
♦ 5-year guarantee.
Technical Data | |
Input Voltage/Hz | AC200-240V 50/60Hz |
Output Voltage/Current | DC35V/590mA |
Power | 25W(HEP DALI) | 26W(TRIDONIC DALI) |
Rated Input Current | 0.125A(HEP DALI) | 0.13A(TRIDONIC DALI) |
THD | <13% |
PF value | >0.9(HEP DALI) | >0.95(TRIDONIC DALI) |
Ingress Protection | IP20 |
Operating Temperature | -10-40℃ |
Dimmability | HEP (with NFC) DALI TRIDONIC DALI |
Optical Data | |
LED Brand | Bridgelux COB LED |
CRI | Ra>80, Ra>90 |
Beam Angle | 15°/25°/38°/60° |
Colour temperature | 2700K/3000K/4000K |
System luminous efficacy up to 83lm/W |
Packaging | |
Box Dimensions | L296×W198×H68mm |
Box Net Weight | 0.428kg |
Box Gross Weight | 0.546kg |
Carton Dimensions | L610×W310×H292mm/12PCS |
Carton Net Weight | 5.136kg |
Carton Gross Weight | 6.552kg |
