♦ 5 CCT changeable with CCT controller.
♦ Fit in most of MR16 downlight converters.
♦ 3-year guarantee.
Technical Data | |
Input Voltage/Hz | AC200-240V 50/60Hz |
Output Voltage/Current | DC34V/120mA(THA) | DC35V/130mA(THU) |
Power | 6W |
Rated Input Current | 0.03A |
THD | ≤40% |
PF value | >0.9 |
Ingress Protection | IP40 |
Operating Temperature | -10-40℃ |
Dimmability | Triac dimmable with DIMMATE driver |
Optical Data | |
LED Brand | EVERCORE COB LED |
CRI | Ra>80, Ra>90 |
SDCM | <6 |
Beam Angle | 15°/24°/36°/60° |
Colour temperature | 2700K-3000K-4000K-5000K-5700K |
System luminous efficacy up to 106lm/W |
Packaging | |
Box Dimensions | L130×W80×H110mm |
Box Net Weight | 0.235kg |
Box Gross Weight | 0.29kg |
Carton Dimensions | L540×W415×H350mm/60PCS |
Carton Net Weight | 14.1kg |
Carton Gross Weight | 18.4kg |
